Portable 6-in-1 Gas Detector (BTYQ-MS600-S)

Detection Method: Built-in pump-suction mechanism; sampling flow rate of 0.5–1 L/min, with ≥10 adjustable flow levels.

Detection Gas: The gases detected include toxic gases, combustible gases, oxygen, carbon dioxide, VOCs, and others, depending on the on-site environment and user requirements.

(Over 500 detectable gas types available, please consult our customer service)

Measurement Range: Depends on the on-site environment and user requirements.

(Customizable measurement ranges available, please consult our customer service)

Customization: Supports on-demand customization

Hotline: 13480931872

Get Quote Back to List

Product ParametersCommon Gas ListProduct IntroductionProduct Details

Item	Parameter
Detection Gas	The gases detected include toxic gases, combustible gases, oxygen, carbon dioxide, VOCs, and others, depending on the on-site environment and user requirements.
Product Features
Detection Range	Depends on the on-site environment and user requirements.
Resolution	0.001 ppm (0–10 ppm, high precision) / 0.01 ppm (0–10 ppm); 0.01 ppm (0–100 ppm), 0.1 ppm (0–1000 ppm), 1 ppm (0–1000 ppm and above); 0.1% LEL; 0.1%, 0.01% Vol
Typical Accuracy	≤±2% FS (Higher-precision sensors available as an option)
Detection Method	Built-in pump-suction mechanism; sampling flow rate of 0.5–1 L/min, with ≥10 adjustable flow levels.
Display	3.5-inch HD Color Touchscreen, IPS Wide Viewing Angle
Power Supply	DC7.4V
Maximum Power Consumption
Operating Environment	Temperature: -20°C to +55°C (customizable to -40°C to +70°C); Relative Humidity: 10–95% RH
Data Storage	The standard capacity exceeds 1 million records; an optional high-capacity storage card is available, supporting on-device viewing, deletion, or data export, with fully customizable storage intervals.
Printing Function
Signal Output
Alarm Method	Fall Detection Alarm
Fall Alarm
Wireless Transmission	Supports simultaneous Bluetooth, Wi-Fi, LoRa/LoRaWAN, Mesh, 4G, or NB-IoT connectivity.
Dimensions: LWH	Maximum dimensions: 188 × 85 × 55 mm (L × W × H), excluding the thickness of the belt clip.
Weight	Approx. 530g
Protection Level
Standard Accessories	T-fittings, filter, 0.2m gooseneck sampling probe, user manual, certificate of conformity, USB charger (with data cable), instrument carrying case.
Optional Accessories	1. Multiple filters; 2. Activated carbon filter; 3. 0.4m stainless steel sampling probe (including 1m hose) and high-temperature sampling probe; 4. 0.9m retractable sampling probe (including 1m hose); 5. External Bluetooth printer.

Common Gases Reference Table (Other ranges and corresponding resolutions not listed below are available upon request):

Detected Gas	Range	Resolution		Detected Gas	Range	Resolution
VOCs (VOC)	1 ppb – 10,000 ppm	1 ppb		Hydrogen Cyanide (HCN)	0 – 30 ppm	0.01 ppm
VOCs (VOC)	0 – 20 ppm	0.01 ppm		Hydrogen Cyanide (HCN)	0 – 100 ppm	0.01 ppm
VOCs (VOC)	0 – 200 ppm	0.01 ppm		Hydrogen Chloride (HCl)	0 – 20 ppm	0.01 ppm
VOCs (VOC)	0 – 2,000 ppm	0.1 ppm		Hydrogen Chloride (HCl)	0 – 200 ppm	0.1 ppm
Combustible Gas (EX)	0 – 100% LEL	0.1% LEL		Phosphine (PH3)	0 – 5 ppm	0.001 ppm
Combustible Gas (EX)	0 – 100% Vol	0.01% Vol		Phosphine (PH3)	0 – 20 ppm	0.01 ppm
Methane (CH4)	0 – 100% LEL	0.1% LEL		Phosphine (PH3)	0 – 2,000 ppm	0.1 ppm
Methane (CH4)	0 – 100% Vol	0.01% Vol		Chlorine Dioxide (ClO2)	0 – 1 ppm	0.001 ppm
Oxygen (O2)	0 – 30% Vol	0.01% Vol		Chlorine Dioxide (ClO2)	0 – 10 ppm	0.01 ppm
Oxygen (O2)	0 – 100% Vol	0.01% Vol		Chlorine Dioxide (ClO2)	0 – 100 ppm	0.01 ppm
Carbon Monoxide (CO)	0 – 50 ppm	0.01 ppm		Ethylene Oxide (ETO) 0-100 ppm	0.01 ppm
Carbon Monoxide (CO)	0-500 ppm	0.1 ppm		Ethylene Oxide (ETO)	0-1000 ppm	0.1 ppm
Carbon Monoxide (CO)	0-1000 ppm	0.1 ppm		Ethylene Oxide (ETO)	0-100% LEL	0.1% LEL
Carbon Monoxide (CO)	0-5000 ppm	0.1 ppm		Phosgene (COCl2)	0-1 ppm	0.001 ppm
Carbon Monoxide (CO)	0-100,000 ppm	1 ppm		Silane (SiH4)	0-1 ppm	0.001 ppm
Carbon Dioxide (CO2)	0-5000 ppm	1 ppm		Silane (SiH4)	0-50 ppm	0.01 ppm
Carbon Dioxide (CO2)	0-50,000 ppm	1 ppm		Fluorine (F2)	0-1 ppm	0.001 ppm
Carbon Dioxide (CO2)	0-5% Vol	0.01% Vol		Fluorine (F2)	0-10 ppm	0.01 ppm
Carbon Dioxide (CO2)	0-20% Vol	0.01% Vol		Fluorine (F2)	0-100 ppm	0.01 ppm
Carbon Dioxide (CO2)	0-50% Vol	0.01% Vol		Hydrogen Fluoride (HF)	0-10 ppm	0.01 ppm
Carbon Dioxide (CO2)	0-100% Vol	0.01% Vol		Hydrogen Fluoride (HF)	0-50 ppm	0.01 ppm
Formaldehyde (CH2O)	0-10 ppm	0.001 ppm		Hydrogen Bromide (HBr)	0-50 ppm	0.01 ppm
Formaldehyde (CH2O)	0-50 ppm 0.01 ppm		Diborane (B2H6)	0–10 ppm	0.001 ppm
Formaldehyde (CH2O)	0–100 ppm	0.01 ppm		Arsine (AsH3)	0–1 ppm	0.001 ppm
Formaldehyde (CH2O)	0–1000 ppm	0.1 ppm		Arsine (AsH3)	0–10 ppm	0.001 ppm
Ozone (O3)	0–1 ppm	0.001 ppm		Arsine (AsH3)	0–10 ppm	0.01 ppm
Ozone (O3)	0–10 ppm	0.001 ppm		Germane (GeH4)	0–2 ppm	0.001 ppm
Ozone (O3)	0–100 ppm	0.01 ppm		Germane (GeH4)	0–50 ppm	0.01 ppm
Ozone (O3)	0–2000 ppm	0.1 ppm		Hydrazine (N2H4)	0–1 ppm	0.001 ppm
Hydrogen Sulfide (H2S)	0–10 ppm	0.001 ppm		Hydrazine (N2H4)	0–300 ppm	0.1 ppm
Hydrogen Sulfide (H2S)	0–100 ppm	0.01 ppm		Tetrahydrothiophene (THT)	0–50 mg/m³	0.01 mg/m³
Hydrogen Sulfide (H2S)	0–500 ppm	0.1 ppm		Bromine (Br2)	0–10 ppm	0.001 ppm
Hydrogen Sulfide (H2S)	0–2000 ppm	0.1 ppm		Bromine (Br2)	0–50 ppm	0.01 ppm
Sulfur Dioxide (SO2) 0-10 ppm	0.001 ppm		Acetylene (C2H2)	0-100% LEL	0.1% LEL
Sulfur Dioxide (SO2)	0-50 ppm	0.01 ppm		Acetylene (C2H2)	0-100 ppm	0.01 ppm
Sulfur Dioxide (SO2)	0-100 ppm	0.01 ppm		Acetylene (C2H2)	0-1000 ppm	0.1 ppm
Sulfur Dioxide (SO2)	0-500 ppm	0.1 ppm		Ethylene (C2H4)	0-100% LEL	0.1% LEL
Sulfur Dioxide (SO2)	0-5000 ppm	0.1 ppm		Ethylene (C2H4)	0-100 ppm	0.01 ppm
Nitric Oxide (NO)	0-10 ppm	0.001 ppm		Ethylene (C2H4)	0-1000 ppm	0.1 ppm
Nitric Oxide (NO)	0-50 ppm	0.01 ppm		Ethyl Mercaptan (C2H5SH)	0-10 mg/m³	0.01 mg/m³
Nitric Oxide (NO)	0-100 ppm	0.01 ppm		Ethanol (C2H6O)	0-100% LEL	0.1% LEL
Nitric Oxide (NO)	0-500 ppm	0.1 ppm		Ethanol (C2H6O)	0-100 ppm	0.01 ppm
Nitric Oxide (NO)	0-5000 ppm	0.1 ppm		Ethanol (C2H6O)	0-2000 ppm	0.1 ppm
Nitrogen Dioxide (NO2)	0-10 ppm	0.001 ppm		Methanol (CH6O)	0-100% LEL 0.1% LEL
Nitrogen Dioxide (NO2)	0-50 ppm	0.01 ppm		Methanol (CH6O)	0-100 ppm	0.01 ppm
Nitrogen Dioxide (NO2)	0-100 ppm	0.01 ppm		Methanol (CH6O)	0-2000 ppm	0.1 ppm
Nitrogen Dioxide (NO2)	0-500 ppm	0.1 ppm		Carbon Disulfide (CS2)	0-50 ppm	0.01 ppm
Nitrogen Dioxide (NO2)	0-5000 ppm	0.1 ppm		Acrylonitrile (C3H3N)	0-100 ppm	0.01 ppm
Nitrogen Oxides (NOx)	0-10 ppm	0.001 ppm		Dinitrogen Tetroxide (N2O4)	0-100 ppm	0.01 ppm
Nitrogen Oxides (NOx)	0-100 ppm	0.01 ppm		Nitrous Oxide (N2O)	0-1000 ppm	1 ppm
Nitrogen Oxides (NOx)	0-500 ppm	0.1 ppm		Methylamine (C3H9N)	0-50 ppm	0.01 ppm
Nitrogen Oxides (NOx)	0-5000 ppm	0.1 ppm		Nitrogen (N2)	0-100% Vol	0.01% Vol
Chlorine (Cl2)	0-10 ppm	0.001 ppm		Sulfur Hexafluoride (SF6)	0-1000 ppm	1 ppm
Chlorine (Cl2)	0-20 ppm	0.01 ppm		Benzene (C6H6)	0-200 ppm	0.1 ppm
Chlorine (Cl2)	0-200 ppm	0.1 ppm		Toluene (C7H8)	0-200 ppm	0.1 ppm
Ammonia (NH3)	0-10 ppm 0.001 ppm		Xylene (C8H10)	0–200 ppm	0.1 ppm
Ammonia (NH3)	0–50 ppm	0.01 ppm		Styrene (C8H8)	0–200 ppm	0.1 ppm
Ammonia (NH3)	0–100 ppm	0.01 ppm		Styrene (C8H8)	0–5000 ppm	0.1 ppm
Ammonia (NH3)	0–1000 ppm	0.1 ppm		Vinyl Chloride (C2H3Cl)	0–200 ppm	0.1 ppm
Ammonia (NH3)	0–5000 ppm	0.1 ppm		Trichloroethylene (C2HCl3)	0–200 ppm	0.1 ppm
Ammonia (NH3)	0–100% LEL	0.1% LEL		Tetrachloroethylene (PID) (C2Cl4)	0–200 ppm	0.1 ppm
Hydrogen (H2)	0–100% LEL	0.1% LEL		Bromomethane (CH3Br)	0–200 ppm	0.1 ppm
Hydrogen (H2)	0–1000 ppm	0.1 ppm		Sulfuryl Fluoride (SO2F2)	0–200 g/m³	0.1 g/m³
Hydrogen (H2)	0–20,000 ppm	1 ppm		Refrigerant (R134a)	0–1000 ppm	1 ppm
Hydrogen (H2)	0–40,000 ppm	1 ppm		Refrigerant (R14)	0–1000 ppm	1 ppm
Hydrogen (H2)	0–100% Vol	0.01% Vol		Refrigerant (R32)	0–1000 ppm	1 ppm
Helium (He) 0–100,000 ppm	10 ppm		Refrigerant (R1234ze)	0–1,000 ppm	1 ppm
Helium (He)	0–100% Vol	0.01% Vol		Refrigerant (R1234yf)	0–1,000 ppm	1 ppm
Argon (Ar)	0–100% Vol	0.01% Vol		Refrigerant (R22)	0–1,000 ppm	1 ppm
Refrigerant (CFC)	0–1,000 ppm	1 ppm		Heptafluoropropane (C3HF7)	0–1,000 ppm	1 ppm

Note: For other gases not listed in the table above, or for different measurement ranges, please contact us for inquiries.

BTYQ-MS600-S Portable 6-in-1 Gas Detector — Overview:

The BTYQ-MS600-S Portable 6-in-1 Gas Detector is primarily designed for the rapid and accurate detection of gas leaks and for providing alarms when gas concentrations exceed safe limits. The device features a front-mounted digital sensor that can be replaced without disassembling the unit. Each digital sensor is "plug-and-play" and features intelligent recognition capabilities, allowing for the simultaneous configuration of multiple individual digital sensors to detect a wider variety of gases. The detector employs various primary sensing principles, including electrochemical, infrared, catalytic combustion, thermal conductivity, and PID (Photoionization Detection). The BTYQ-MS600-S is widely utilized in diverse applications such as firefighting, emergency rescue, confined space operations, petroleum, chemical engineering, metallurgy, refining, gas utilities, warehousing, pharmaceuticals, environmental protection, and air quality management.

BTYQ-MS600-S Portable 6-in-1 Gas Detector — Key Features:

★ Built-in pump-driven sampling system.

★ Pump blockage alarm.

★ Integrated LED illumination.

★ Utilizes digital sensors: each sensor is hot-swappable, features intelligent recognition, is "plug-and-play," requires no calibration, and can be inserted into any available sensor slot.

★ Individual sensors can be enabled or disabled via the device menu settings.

★ Alarms for missing sensors and early warnings for sensors nearing the end of their service life.

★ Features a front-mounted digital sensor that can be replaced without disassembling the device.

★ Unit switching capability; selectable units include: μmol/mol, ppm, pphm, ppb, mg/m³, μg/m³, %Vol, and %LEL.

★ User interface features 4 physical buttons combined with a touchscreen; includes a quick one-touch calibration function.

★ 3.5-inch high-definition color touchscreen display with IPS wide-angle viewing and capacitive touch technology.

★ Data storage capability: standard capacity exceeds 1 million data entries; supports an optional high-capacity storage card for storing over 10 million data entries.

★ Communication Interface: Type-C port for both fast charging and data communication.

★ Optional Wireless Transmission: Simultaneously supports Bluetooth, Wi-Fi, LoRa/LoRaWAN, MESH, 4G/NB-IoT, and other protocols; includes a signal strength indicator. Wi-Fi and 4G connectivity support communication protocols such as HTTP, MQTT, TCP, and UDP. ★ Optional Features: BeiDou positioning; one-touch location upload to cloud platform; wireless interconnection between multiple devices; support for viewing via mobile apps; remote alarming; notifications via phone calls, SMS, and WeChat.

★ Supports remote maintenance and remote firmware upgrades.

★ Fall detection alarm.

★ SOS one-touch emergency call (motion-triggered alarm, active distress signal); "Lazy Clock" (inactivity reminder) function.

★ Data recovery function: allows for the partial or complete restoration of factory default settings.

★ Built-in gas library (covering combustible gases, VOCs, and toxic gases).

★ Displays maximum, minimum, and weighted average values; supports real-time curve graphs, bar charts, and list views.

★ Multiple selectable alarm tones; alarm tones can be configured independently for each type; alarm volume exceeds 95 dB at a distance of 30 cm.

★ Multiple alarm methods and modes available; supports the configuration of multiple alarm thresholds; alarms can be disabled.

Alarm Methods: Audible/visual alarm, vibration alarm, voice alarm.

Alarm Types: Concentration alarm, low battery alarm, fault alarm, pump blockage alarm, fall detection alarm, SOS alarm (motion-triggered alarm).

Alarm Modes: Low-level alarm, high-level alarm, range alarm, TWA/STEL alarms.

★ Accidental operation detection function.

★ Automatic zero-point tracking.

★ Multi-point span calibration.

★ Intrinsically safe circuit design; features explosion-proof, vibration-resistant, anti-static, and anti-radiation capabilities.

★ IP68 protection rating. ★ Applicable Standards:

GB/T 3836.1-2021 — *Electrical Equipment for Explosive Gas Atmospheres — General Requirements*

GB/T 3836.4-2021 — *Electrical Equipment for Explosive Gas Atmospheres — Intrinsic Safety "i"*

GB 15322.3-2019 — *Flammable Gas Detectors — Part 3: Portable Flammable Gas Detectors for Industrial and Commercial Use*

GB/T 20936.1-2022 — *Gas Detectors for Explosive Atmospheres — Part 1: Performance Requirements for Flammable Gas Detectors*

GB 12358-2024 — *General Technical Requirements for Gas Detection and Alarm Instruments in Workplaces*

BTYQ-MS600-S Portable 6-in-1 Gas Detector — Outline Drawing:

Built-in Pump-Suction + Detachable Probe Built-in Pump-Suction + Detachable Probe + Gooseneck Sampling Probe

Product HighlightsNew process formula enhances performance to meet stricter application requirements

High PrecisionUp to ±0.1%FS (varies by gas type)
Wireless ConnectivityOptional wireless communication for real-time data monitoring
Advanced ProtectionIP67+ protection level
Explosion-proof DesignHigh shock and explosion resistance
Anti-interference DesignAnti-static and electromagnetic interference
HD Color DisplayComprehensive and clear information display
Large Capacity StorageMassive data storage
Multiple Transmission MethodsUSB, infrared, RS232, Bluetooth, WiFi

500+ Detectable Gases

Customize according to requirements 1-18 typesDetecting gas combinations
