Coal-burning boiler online sulfur dioxide flue gas monitor Overview

The equipment installation location is between the primary desulfurization tower and the secondary desulfurization tower of the coal-fired boiler. There is a CEMS monitor at the entrance of the primary desulfurization tower. The concentration of SO2 is 2000mg/m3, up to 3000mg/m3. The purpose of monitoring the numerical size of sulfur dioxide at this position is Do not add desulfurization reactants in the secondary desulfurization and denitrification tower.

Parameter requirements:

1. Online SO2 detector

2. Measurement composition: SO2 in flue gas,

3. Flue gas pressure: 1 to 3kPa,

4. Accuracy: ±2%FS,

5.Flue size: 4200 mm (diameter) × 6 mm (wall thickness),

6. Probe material: 316L wear-resistant and corrosion-resistant,

7. Sampling tube length: 5 meters, power supply: 220VAC, 50Hz, signal: 4~20mA,

8. Protection level: IP65. Equipped with on-site analysis cabinet (with outdoor rain cover),

9. Measurable range: 0~1200mg/Nm3,

10. Normal range: <600mg/Nm3,

11. Medium: raw flue gas 50~80℃,

12. Connection method: flange, connection material: 304SS,

13.Connection size: DN50 PN16

Model: Nitrogen Oxide Online Monitoring System TH-2000 Fixed Sulfur Dioxide Gas Detector MIC-600-SO2
